WFC1-PS70-30-H

Order Code14557

WFC1 Full Cutoff Wall Pack, PowerSet 70/60/45W, 3000K, 120-347V, 0-10V Dimming, Photocell

Resources

No accessories available.
No controls available.

WFC1-PS70-30-H

Order Code14557

WFC1 Full Cutoff Wall Pack, PowerSet 70/60/45W, 3000K, 120-347V, 0-10V Dimming, Photocell

Availability
USA, CANADA
Ordering Information
UPC CODE031293145574
Order Multiple1
Case Qty1
Pallet Qty
Product Specifications
Voltage120-347VAC
Lumens (lm)5,850 / 7,800 / 9,100 lm
Wattage70W / 60W / 45W
Efficacy (lm/W)130
CCT (K)3000K
DimmingYes
Energy StarNo
IP RatingIP65
Wet/Damp/Dry LocationWet
IK RatingIK10
RoHS CompliantYes
FCC CompliantNo
UL / ETLYes - UL
Dimensions (L x W x H)W: 12 5/8" (320mm), H: 6 13/16" (173mm), D: 5 3/16" (131mm)
Lens MaterialPolycarbonate (PC)
Operating Temp Range (°F/°C)-40F to 104F (-40C to 40C)
Driver Surge Protection (kV) new4kV
Auxiliary Output12V
BrandEiKO
