VP3-2PS25-FCCT-H

Order Code:13737

VP3 Vapor Proof Fixture, 2', PowerSet 25/20/15W, FieldCCeT 3500/4000/5000K, 120-347V, 0-10V Dimming


Product Specifications
Input Voltage120-347VAC
Lumens (lm)3,500 / 2,800 / 2,100 lm
Wattage25W / 20W / 15W
Efficacy (lm/W)140
CCT3000K / 4000K / 5000K
CRI80+
Dimming0-10V
Nominal Size2 Foot
DLC VersionDLC 5.1 Premium
TITLE 20Exempt
TITLE 24/JA8No
Energy StarNo
IP RatingIP66
UL Location RatingWet
Other RatingsIK10; NSF
RoHS CompliantYes
FCC CompliantYes
UL / ETLYes - UL
Dimensions (L x W x H)L: 24.8" (630mm), W: 5.0" (127mm) H: 3.6" (91mm)
ColorGray
Lens Material NewPolycarbonate (PC)
Operating Temp Range (°F/°C)-40F to 122F (-40C to 50C), suspended mount / -40F to 113F (-40C to 45C), surface mount
Surge Protection (kV)2.5kV
Auxiliary Output12V, 100mA
Warranty5 Years
BrandEiKO
