CSX1-8PS90-FCCT-H

Order Code:13638

CSX1 Commercial Strip Premium, PowerSet 90/75/65W, FieldCCeT 3500/4000/5000K, 120-347V, 0-10V Dimming

AVAILABILITY:  USA, CANADA

Suggested Alternative Items

CSX1-8PS90-FCCT-U

Product Specifications
Input Voltage120-347VAC
Lumens (lm)11,700 / 9,750 / 8,450 lm
Wattage90W / 75W / 65W
Efficacy (lm/W)130
CCT3000K / 4000K / 5000K
CRI80+
Dimming0-10V
Nominal Size8 Foot
Replacement For/Equivalent2 lamp 86W T8 / 4 lamp 32W T8
Energy StarNo
IP RatingIP20
UL Location RatingDamp
RoHS CompliantNo
FCC CompliantNo
Dimensions (L x W x H)L: 94 3/16" (2392 mm), W: 2 13/16" (72 mm), H: 2 1/2" (64 mm)
ColorWhite
Lens MaterialAcrylic (PMMA)
Operating Temp Range (°F/°C)-4F to 122F (-20C to 50C)
Surge Protection (kV)2.5kV
Auxiliary Output12V, 100mA
Warranty5 Years
BrandEiKO
